Name: Marin 2022 Rift Zone 2 29
SKU: 274476

Marin 2021 Rift Zone 2 29

FAST PACED, EPIC RIDES

PUSHING THE ENVELOPE UP AND DOWN THE TRAIL

CHASING PERSONAL RECORDS

The Rift Zone is our most speed oriented MultiTrac bike, created for the rider looking for the speed and roll over capabilities of 29” wheels in a trail capable package. Long, low, and slack trail geometry is more aggressive than an XC race bike for more control at top speed, and more fun while chasing seconds.

Specifications

Marin 2022 Rift Zone 2 29

Frame

Colour: Teal/Silver/Black
Frame: Series 3 6061 Aluminum Frame, 29” Wheels, 125mm Travel, MultiTrac Suspension Platform, 148x12 Boost Spacing2, 73mm Threaded BB w/ ISCG05 Tabs
Fork: RockShox Recon Silver RL 29", 130mm Travel, Solo Air, Compression and Rebound Adjustment, Alloy Tapered Steerer, Fast Black Uppers, 110x15mm Boost Spacing, Maxle Stealth, 42mm Offset
Shock: RockShox Deluxe Select R, Debonair Air Sleeve, Rebound Adjustment, Custom Tune, 210x50mm, M8x25mm Hardware
Weight: N/A

Drivetrain

Crankset: FSA Comet, Modular 1x, 32T Direct Mount Chainring, MegaTooth Technology, Boost Spacing
Pedals: N/A
Chain: KMC X-12 Silver and Black
Bottom Bracket: External Sealed Cartridge Bearing
Rear Derailleur: Shimano Deore, 12-Speed, SGS
Front Derailleur: N/A
Derailleur Shifter: Shimano Deore, 12-Speed, SL-6100IR
Freewheel/Cassette: Shimano, Deore M6100, 12-Speed, 10-51T

Wheels

Tyres: Vee Tire Flow Snap 29x2.35", Tackee Compound, Tubeless Ready
Wheels/Rims: Marin, Double Wall Alloy, 29mm Inner, Pinned Joint, Disc Specific, 32H, Tubeless Compatible
Hubs: Front: Shimano HF-MT410B, 110x15mm, Centerlock Rear: Shimano HB-MT410B, 148x12mm, Centerlock, Microspline Freehub Body

Braking System

Brakes: Shimano BR-MT200 Hydraulic Disc, 180mm Rotor
Brake Levers: Shimano BR-MT201 Hydraulic Disc

Other

Handle Bar: Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back
Stem: Marin 3D Forged Alloy, 35mm
Seat Post: TranzX, YSP23JL, 1x Remote, Size S 125mm Travel, Size M and L 150mm Travel, Size XL 175mm Travel, 30.9mm
Saddle: Marin Speed Concept

Geometry

Marin 2022 Rift Zone 2 29

S	M	L	XL
STACK	602.6	607.15	611.7	616.25
REACH	430	455	480	505
HEADTUBE ANGLE	65.5°	65.5°	65.5°	65.5°
HEADTUBE LENGTH	100	105	110	115
SEATTUBE ANGLE	76°	76°	76°	76°
SEATTUBE LENGTH	390	400	425	430
TOPTUBE EFFECTIVE	580.24	606.36	632.51	658.6
BB HEIGHT	344	344	344	344
BB DROP	34	34	34	34
CHAINSTAY	425	425	425	425
WHEELBASE	1158.92	1186	1213	1240.1
STANDOVER HEIGHT	691.84	697.1	717.83	721.97
FORK OFFSET	44	44	44	44
SEATPOST DIAMETER	30.9	30.9	30.9	30.9
HANDLEBAR WIDTH	780	780	780	780
STEM LENGTH	35	35	35	35
CRANK LENGTH	170	175	175	175
